DuraDoor
Adaptable, high security, high-quality door
Rigid aluminium construction, and flexible in application, the DuraDoor seamlessly integrates into a multitude of materials.
DuraDoor – Quality Metal Egress Doors
AceDoors DuraDoor, designed to be installed into pre-cast concrete, timber, or block work across a broad range of industries from retail to commercial, sporting to residential.
Manufactured in New Zealand with an injected polyurethane foam core sheathed in powder coated stucco aluminium sheet, warp and rot free, with high-security lock tongue protected by leaf frame overlapping the door facing.
Where form meets function
Color Matching
Powder coated aluminium can be colour matched with the existing building, so no on-site painting is required. Pre-hung in one piece frame with your choice of hardware.
High-Strength
Where timber can warp and rot over time, the DuraDoor remains uncompromising, standing up to humidity, corrosive environments, heavy traffic and repeated washing with unwavering durability.
High-performance
Lightweight yet high-performing, security features a lock tongue protected by a leaf frame overlapping the door facing, with energy-saving polyurethane foam core to deliver exceptional insulation values and full perimeter gasket seals to decrease energy costs and reduce air infiltration.
Enquire about DuraDoor
Interested about using the DuraDoor for your next project? Talk to one of our Specialists today.
Specific to you
Eliminates all swelling, sticking and painting problems associated with timber doors
Can be customised to meet the needs of your project
High-performance construction without the burden of cumbersome weight
Can be supplied as single or double leaf doors
New Zealand made
Tech Specs
Acceptable Manufacturer
Door set shall be “DuraDoor” as supplied by AceDoors Systems 2013 Ltd.
Door Leaf
A. Fabricated from stucco embossed aluminium sheet, which is interlocked into heavy duty aluminium styles and rails.
B. Reinforcement is provided by a polyurethane core injected into the door to give an overall leaf thickness of 42mm.
C. Door leaves are fitted with heavy-duty aluminium rebated hinges.
D. Double door sets feature an astragal fitted to the leading edge of the inactive leaf.
E. The bottom rail edge contain a silicone U-gasket to form a weatherproof threshold seal.
F. Each leaf cannot be bigger than 2300H x 1150W.
Door Frame
A. Robust aluminium profiles designed to overlap the daylight opening of the doorway and fit on the outside face of the wall.
B. Includes rubber gasket seals for weather proofing, absorb shock loading and minimise noise.
Hardware
A. Hardware is factory fitted.
B. Mortice lock backset to be 60mm.
C. Standard hardware and furniture is Legge V31 Mortise Lock with Legge 702 Alpha SCP External & Legge 712 Alpha SCP Internal.
D. Optional non-standard hardware available at additional cost, including electronic locks.
E. Master keying to be done on site.
Finish
A. Doors and frames are powder coated finished in a standard colour from the Duralloy range to suit your colour requirements.
B. Non-standard colours attract a surcharge.
Optional Extras
A. Various glazing options are available.
B. Louvred panels are available.
C. Kick plates available – stainless steel or checker plate.
D. Full surround frame.
E. Open-In Frame.
F. Door closer and panic bar hardpoints.
G. Anti Jemmy Bar.
Manufacturing Quality
With over 30 years’ experience in the market, we know how to deliver a product with longevity, with less overall maintenance requirements, and lower temperature loss, resulting in greater energy savings.
Manufactured from our Auckland Factory
All our AceDoors DuraDoors doors are manufactured in our Auckland factory, adapted to the site and requirements of the individual client. With your needs in mind, we have the agility and experience to deliver an exceptional product at a competetive rate with outsanding service.
